Optimum use of space
With the tailor-made META steel building platforms, you can economically double your storage space and create new areas! By building over existing areas such as warehouses, workshops and machine rooms, space can be doubled or tripled. Integrated stairs and elevator systems ensure safe, fast and convenient access to any location in the warehouse. These steel construction platforms are manufactured individually according to customer requirements. The intelligent combination of lightweight platforms with steel construction ensures flexible and efficient solutions.
CONTACT US!
We will find your customized solution together
Discover Our META Products
Need a Consultation?
Find out what your custom solution looks like. Set up a free initial consultation with a Tier1 MRO professional today.
Conveyor systems & automated intralogistics solutions from a single source
META-ILS convinces with individual and holistic customer solutions in the field of warehouse automation. By effectively combining our tried-and-tested racking technology with conveyor systems and automated intralogistics solutions from market-leading partners, we create a sustainable competitive advantage for you.
Catalog project solutions
Discover our META-ILS project references in our flip catalog
Discover Our META Products
Need a Consultation?
Find out what your custom solution looks like. Set up a free initial consultation with a Tier1 MRO professional today.
INFORMATON
Properties
Simple plug-in installation
Quick assembly and conversion without tools
Frame variants
S3 (disassembled) / clinched (prefabricated) frame
Shelf variants
Single/double-sided shelf
Mounting variants
Plug-in assembly with shelf clips + diagonal struts (shelf use on one side) / with longitudinal ledgers (shelf use on both sides)
Extensive range of system accessories
Bin fronts, compartment dividers, storage boxes, drawers, doors,…
Shelving, cabinet and magazine equipment
Flexibly combinable modules based on the CLIP system allow you to customize the equipment according to your requirements
Shelves height-adjustable in 1″ ( 25 mm) increments
for variable adaptation to the stored goods
Shelves with perforations in 2″ (50 mm) increments
For holding compartment dividers or mesh dividers
(exception: 80 kg shelves)
Load data
Shelf load up to 330 kg
Field load up to 4,400 kg
Surface
Sendzimir galvanized or additionally plastic-coated RAL 7035 light grey
Order proposals
Car rack (V-belt rack, exhaust storage rack)
Sign & wire basket rack
HT rack; Corner rack; Work safety rack
Safety Instructions
Shelves with a height/depth ratio ≥ 4 : 1 must be secured against tipping (wall or floor anchoring).
Shelf/ bay loads apply to evenly distributed loads. Bay load specifications apply to rows of shelves with 3 or more bays.
Dimensions
Heights: 1,0001, 1,500, 1,850, 2,000, 2,200, 2,500, 3,000, 3,5001, 4,0001, 4,3001, 4,5001 mm
Depths: 300, 400, 500, 600, 800 mm
Lengths: 750, 1,000, 1.250, 1,300, 1,500, 1,700 mm
1 on request
Basic bay: nominal length + 56 mm – nominal depth +36 mm
Add-on bay: nominal length + 6 mm – nominal depth +36 mm
Discover Our META Products
Need a Consultation?
Find out what your custom solution looks like. Set up a free initial consultation with a Tier1 MRO professional today.
INFORMATON
Properties
Simple plug-in installation
Quick assembly and conversion without tools
Shelves height-adjustable in 25 mm increments
for variable adaptation to the stored goods
Optimum monitoring of stocks
Inclination
Stored goods, such as cartons, slide automatically towards the removal side
incl. cover shelf as dust protection and additional storage space
Load Data
Shelf load up to 200 kg
Filed load up to 1,800 kg
Safety Instructions
Shelves with a height/depth ratio ≥ 4 : 1 must be secured against tipping (wall or floor anchoring).
Shelf/ bay loads apply to evenly distributed loads. Bay load specifications apply to rows of shelves with 3 or more bays.
Dimensions
Heights: 2,000 mm
Lengths: 1,000, 1,300 mm
Depths: 500, 800, 1,228 mm
Discover Our META Products
Need a Consultation?
Find out what your custom solution looks like. Set up a free initial consultation with a Tier1 MRO professional today.
INFORMATON
Properties
pre-packed units
(basic or add-on shelving units), therefore easy handling
and transportation
Simple plug-in installation
Quick assembly and conversion without tools
Extensive range of system accessories
Bin fronts, compartment dividers, storage boxes, …
universally applicable
E.g. for warehouse, workshop, sales room, cellar, office, etc.
Shelves height-adjustable in 1″ (25 mm) increments
for variable adaptation to the stored goods
Shelves with perforations in 2″ (50 mm) increments
For holding compartment dividers or mesh dividers
(exception: 176 lbs (80 kg) shelves)
Load data
Shelf load up to 507 lbs (230 kg)
Field load up to 3638 lbs (1,650 kg)
Surface
Sendzimir galvanized or additionally coated RAL 7035 light grey
Safety Instructions
Shelves with a height/depth ratio ≥ 4 : 1 must be secured against tipping (wall or floor anchoring).
Shelf/ bay loads apply to evenly distributed loads. Bay load specifications apply to rows of shelves with 3 or more bays.
Dimensions
Heights: 79 inch
Depths: 16, 20, 24 inch
Lengths: 30 inch
Heights: 2,000 mm
Depths: 400, 500, 600 mm
Lengths: 1,000 mm
Basic bay: nominal length + 2,2″ (56 mm) – nominal depth + 1,4″ (36 mm)
Add-on bay: nominal length + 0,2″ (6 mm) – nominal depth + 1,4″ (36 mm)
Discover Our META Products
Need a Consultation?
Find out what your custom solution looks like. Set up a free initial consultation with a Tier1 MRO professional today.
INFORMATON
Properties
Simple assembly
Fastening with offset screwdriver, simplified by fixed bracket with integrated thread and lens flange head screws with hexagon socket
Shelves height-adjustable in 1″ ( 25 mm) increments
for variable adaptation to the stored goods
Shelves with perforations in 2″ (50 mm) increments
For holding compartment dividers or mesh dividers (exception: 176 lbs (80 kg) shelves)
Load data
Shelf load up to 507 lbs (230 kg)
Field load up to 3219 lbs (1,460 kg)
Surface
Sendzimir galvanized or additionally plastic-coated RAL 7035 light grey
Note
Each META FIX basic shelf comes with an offset screwdriver (hexagonal)
Safety Instructions
Shelves with a height/depth ratio ≥ 4 : 1 must be secured against tipping (wall or floor anchoring).
Shelf/ bay loads apply to evenly distributed loads. Bay load specifications apply to rows of shelves with 3 or more bays.
Dimensions
Heights: 79, 98 , 118 inch
Lengths: 39 inch
Depths: 12, 16, 20, 24, 31 inch
Heights: 2,000, 2,500, 3,000 mm
Lengths: 1,000 mm
Depths: 300, 400, 500, 600, 800 mm
Basic bay: Nominal length + 0,2″ (4 mm) – nominal depth + 0,2″ (4 mm)
Add-on bay: Nominal length + 0,07″ (2 mm) – nominal depth + 0,2″ (4 mm)
Discover Our META Products
Need a Consultation?
Find out what your custom solution looks like. Set up a free initial consultation with a Tier1 MRO professional today.
SHELVING & STORAGE SYSTEMS
The diversity of our shelving
META CLIP is a versatile shelving system consisting of a frame and shelves that can be assembled without tools using simple plug-in assembly. Alternatively, META FIX can also be used, which is screwed together completely from the outside using an offset screwdriver. Both systems offer flexible height adjustment of the shelves and an extensive range of accessories for a wide variety of stored goods. Ideal for small parts storage in industry, trade and commerce.
Discover Our META Products
Need a Consultation?
Find out what your custom solution looks like. Set up a free initial consultation with a Tier1 MRO professional today.
Quality and Innovation at all levels
Discover Our META Products
Need a Consultation?
Find out what your custom solution looks like. Set up a free initial consultation with a Tier1 MRO professional today.
INFORMATON
Properties
Simple plug-in installation
Quick assembly and conversion without tools
Extensive range of system accessories
Bin fronts, compartment dividers, storage boxes, …
Shelves height-adjustable in 25 mm increments
for variable adaptation to the stored goods
Load data
Shelf payload up to 100 kg
Field load: Corner shelving up to 1,200 kg // Add-on shelving up to 2,400 kg
Safety Instructions
Shelves with a height/depth ratio ≥ 4 : 1 must be secured against tipping (wall or floor anchoring). Shelf/ bay loads apply to evenly distributed loads. Bay load specifications apply to rows of shelves with 3 or more bays.
Dimensions
Heights: 2,000, 2,500 mm
Depths: 300, 400, 500, 600 mm
Discover Our META Products
Need a Consultation?
Find out what your custom solution looks like. Set up a free initial consultation with a Tier1 MRO professional today.
INFORMATON
Properties
Simple plug-in installation
Quick assembly without tools
Tray floors
With ÜHP mark: suitable for the storage of water-polluting liquids WGK 1-3 and flammable liquids F / F+
Fluid capacity
Each shelf 28 liters, type
Drip tray
With ÜHP mark, type suitable for the storage of water-polluting liquids WGK 1-3 and flammable liquids F / F+, collection volume 45 liters
Shelves height-adjustable in 25 mm increments
for variable adaptation to the stored goods
Shelves with perforations in 50 mm increments
For holding compartment dividers or mesh dividers
Load data
Shelf load up to 150 kg
Field load up to 1,100 kg
Safety Instructions
Shelves with a height/depth ratio ≥ 4 : 1 must be secured against tipping (wall or floor anchoring).
Shelf/ bay loads apply to evenly distributed loads. Bay load specifications apply to rows of shelves with 3 or more bays.
Dimensions
Heights: 2,000 mm
Lengths: 1,000 mm
Depths: 500 mm
